General |
Device type | Wi-Fi range extender |
Width | 5.07 cm |
Depth | 4.87 cm |
Height | 9.79 cm |
Weight | 116 g |
Networking |
Form factor | In-wall mountable |
Connectivity technology | Wireless |
Data link protocol | Ethernet, Fast Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
Frequency band | 2.4 GHz (1 band) / 5 GHz (2 bands) |
Wi fi rating | AC750 |
Status indicators | Status, signal strength, WPS |
Features | Wi-Fi Protected Setup (WPS) |
Encryption algorithm | WPA, WPA2 |
Compliant standards | IEEE 802.3ab, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
Aerial |
Antenna | External integrated |
Antenna qty | 2 |
Expansion connectivity |
Interfaces | 1 x 100Base-TX - RJ-45 |
Miscellaneous |
Compliant standards | UL, IC, FCC |
Power |
Power device | Internal power supply |
Voltage required | AC 120/230 V (50/60 Hz) |
Environmental parameters |
Min operating temperature | 0 °C |
Max operating temperature | 35 °C |
Humidity range operating | 10 - 90% (non-condensing) |
