| General |
| Device type | UPS - external |
| Battery enclosure type | Plug-in module |
| Height rack units | 2U |
| Power device |
| Ups technology | On-line |
| Input voltage range | AC 120 - 280 V |
| Frequency provided | 50/60 Hz |
| Frequency required | 40 - 70 Hz |
| Input connectors | 1 x power IEC 60320 C14 |
| Power output connectors details | 8 x power IEC 60320 C13 |
| Output voltage | AC 200/208/220/230/240 V ± 2% - 50/60 Hz |
| Power capacity | 1350 Watt / 1500 VA |
| Dataline surge protection | Network/phone line - RJ-45/RJ-11 |
| Output waveform | Sinewave |
| Surge suppression | Yes |
| Efficiency | 93% |
| Battery |
| Quantity | 3 |
| Technology | Lead Acid |
| Voltage provided | 12 V |
| Capacity | 9 Ah |
| Run time up to | 3 min at full load 9 min at half load |
| Recharge time | 5 hours |
| Networking |
| Remote management interface | RS-232, USB |
| Expansion connectivity |
| Interfaces | 1 x management (RS-232) - 9 pin D-Sub (DB-9) 1 x management (USB) - 4 pin USB Type B 1 x EPO (emergency power off) |
| Expansion slots | 1 (total) / 1 (free) x Expansion Slot |
| Miscellaneous |
| Equipment protection value | 100000 Euros |
| Features | Audible alarm, LCD display, LED indicators, overload protection, cold-start function, short-circuit protection, Eco-efficiency, temperature controlled fan, Smart Battery Management (SMB) |
| Compliant standards | IEC 61000-4-5, PCT, RoHS |
| Software system requirements |
| Software included | PowerPanel Business Edition |
| Os required | Apple MacOS, Linux, Microsoft Windows 2000 Professional, Microsoft Windows 98/ME, Microsoft Windows Vista / XP / 7, Microsoft Windows 2003, Microsoft Windows Server 2008 |
| Manufacturer warranty |
| Service support | Limited warranty - batteries - 3 years |
| Dimensions weight |
| Width | 43.3 cm |
| Depth | 43 cm |
| Height | 8.8 cm |
| Weight | 18 kg |
