| General |
| Printer type | Label printer - direct thermal - two-colour (monochrome) |
| Localisation | Australia |
| Printer |
| Print speed | Up to 93 labels/min Up to 148 mm/sec |
| Built in devices | Status LCD |
| Connectivity technology | Wired |
| Interface | USB 2.0 |
| Max resolution b w | 300 x 600 dpi |
| Auto cutter | Yes |
| Barcodes | Code 39, QR code, MaxiCode, UPC-A, UPC-E, Codabar, Code 128, Postnet, PDF417, Data Matrix, ITF, EAN-8, EAN-13, ISBN-2, ISBN-5 |
| Printer features | Auto Power Off |
| Media handling |
| Media type | Die cut labels, label continuous paper |
| Compatible tapes | DK tape |
| Max media size | Roll (6.2 cm) |
| Max media size custom | 62 mm |
| Media sizes | Roll (2.9 cm), Roll (5.4 cm), Roll (2.4 cm), Roll (1.2 cm), Roll (3.8 cm), Roll (5.8 cm), Roll (6.2 cm), Roll (5 cm), 17 x 87 mm, 17 x 54 mm, 29 x 90 mm, 38 x 90 mm, 62 x 100 mm, 62 x 29 mm |
| Max printing width | 58 mm |
| Max printing length | 1 m |
| Media feeders | 1 x manual - 1 roll - Roll (6.2 cm) |
| Expansion connectivity |
| Connections | 1 x USB 2.0 |
| Miscellaneous |
| Media included | DK-11201 die-cut standard address labels (100 labels), DK-22251 62 mm continuous length black/red on white paper tape 5 m |
| Power |
| Power device | Power supply - internal |
| Voltage required | AC 230V |
| Frequency required | 50/60 Hz |
| Software system requirements |
| Os required | Linux, Microsoft Windows Vista (32/64 bits), Microsoft Windows 7 (32/64 bits), Windows 8 (32/64 bits), Apple MacOS X 10.10.x, Windows 10 (32/64 bits), Apple MacOS X 10.11.x, Apple macOS 10.12.x |
| Environmental standards |
| Energy star | Yes |
| Manufacturer warranty |
| Service support | Limited warranty - 3 years |
| Environmental parameters |
| Min operating temperature | 10 °C |
| Max operating temperature | 35 °C |
| Humidity range operating | 20 - 80% |
| Dimensions weight |
| Width | 12.53 cm |
| Depth | 21.3 cm |
| Height | 14.2 cm |
| Weight | 1.15 kg |
